Function and Feature

Gateway for communication between head-endstation and meters

TCP/IP protocol over Ethernet and 2G/3Gmodem uplink with head-end system

RF/ RS485 down-link with meters Javaapplication compatible



Technical Parameter

Operating voltage 1x230V or 3x 230/400V

Voltage range: 0.8 Un – 1.2 Un

Frequency: 50 Hz          Protection Class:  IP54

Storage flash memory: 256MB

EMC compliant with Directive 2004/108/EC

Dimension: 160x112x58 mm    Weight: 0.7kg
